Rotary Tire Machines - Changer and Balancer - $16,350 (Anchorage)
QR Code Link to This Post
The R146 is a high performance swing arm tire changer for the high volume tire center. Exclusive 110V drive motor provides needed torque for handling today’s difficult assemblies. The large and reinforced frame adds greater rigidity to the structure and chucking table. The gear box is installed between two steel plates avoiding flex during operation. The extra height of the vertical post and tool shaft allow operation on tires to a maximum 15” (381 mm) tire width.
High Performance
High Volume
Extra-Height Speed Changer
110v Drive Motor Provides Needed Torque
Hand controlled bead breaker
Made in Italy
Other Features:
Extra large frame allows for a maximum tire diameter of 46″.
New arm design for high performance, high volume, and extra height.
Helper Arm PLUS91SA assists in lower bead demounting, bead top pressing, and a tire lift for large and special tires.
Removable pedal unit for easy maintenance.
Extra wide tool shaft allows operation on tires up to 15″ maximum tire width.
Air tank is encapsulated inside the changer, freeing up space behind the machine.
Standard Equipment:
Rotary VSG800A117 Tool Protection Kit for metal mount/demount head
Rotary VSG800A6 Clamp Protectors (4 pieces)
Rotary VSG800A11 Bead Breaker Protector
Rotary VSG800A60 Plastic Tool Head with Support
Bead Lever
Valve tray
Tire paste lubricant and brush
Warranty: 3 years on parts, 1 year on labor
Specifications:
Rotary Model Number (Electric Motor with Helper Arm) R146RP
Rotary Part Number RWC246.26iRP
External Clamping 10″ - 26″
Maximum Torque to Chuck 885 ft/lbs (1200 Nm)
Internal Clamping 12″ - 28.5″
Maximum Tire Diameter 46″ (1200 mm)
Maximum Rim Width 15″ (380 mm)
Maximum Bead Breaker Opening 15″ (380 mm)
Bead Breaker Cylinder Power at 145 psi 6,745 ft/lbs
Power Supply (Electric Motor) 110 V / 60 Hz / 1 Ph
Power Supply (Air Motor) 100 psi
Rotary R155 Pro 3D Wheel Balancer
3D Technology Electronic Balancer With Microprocessor
Equipped with all the features for the most demanding professional. Easy operation thanks to interactive inputs, which guide the operator during all the phases of the balancing process. Fast balancing process with automatic start when the cover is lowered and automatic stop of the wheel in the external unbalanced position.
Simple visual display
Automatic program
Internal data gauge
Space saving footprint
Made in Italy
Features:
Double LED lights illuminate the base of the wheel while using the distance and diameter gauge
The Laser Blade shines down at the six o’clock position of the wheel to help accurately place stick-on weight
Use the Quick Lock to secure your wheel to the balancer’s shaft in a flash
Linked directly to a standard monitor, the durable touch pad allows for a “gloved” input protecting the monitor from grease and grime
Width Arm Gauge comes as a standard feature with the R155, 3D wheel tire sensor caliper for automatic measure of the rim
Includes a diameter gauge, weight hammer, 3.5oz test weight (100g), 4 wheel cones, and quick lock as standard accessories
Warranty: 3 years on parts, 1 year on labor
Specifications:
Rotary Model Number R155
Rotary Part Number RWB355SB
Rim Diameter 10″ - 30″ Automatic
Rim Width 1.5″ - 22″
Maximum Tire Diameter 44″
Maximum Assembly Weight 154 lbs.
Read Out Accuracy 1 g
Cycle Time 6 seconds
Rotation Speed Less than 100 rpm
Power Supply 100 V / 60 Hz / 1 Ph
